Kinematics and Dynamics of Mechanical Systems, Second Edition: Implementation in MATLAB® and SimMechanics® 2nd edition [Kietas viršelis]

(New Jersey Institute of Technology, USA), (Softalink LLC, USA), (New Jersey Institute of Technology, USA)
  • Formatas: Hardback, 516 pages, aukštis x plotis: 254x178 mm, weight: 1152 g, 212 Tables, black and white; 419 Illustrations, black and white
  • Išleidimo metai: 17-Sep-2018
  • Leidėjas: CRC Press
  • ISBN-10: 1138584045
  • ISBN-13: 9781138584044
Kitos knygos pagal šią temą:
Kinematics and Dynamics of Mechanical Systems, Second Edition: Implementation in MATLAB® and SimMechanics® 2nd editionDidesnis paveikslėlis
  • Formatas: Hardback, 516 pages, aukštis x plotis: 254x178 mm, weight: 1152 g, 212 Tables, black and white; 419 Illustrations, black and white
  • Išleidimo metai: 17-Sep-2018
  • Leidėjas: CRC Press
  • ISBN-10: 1138584045
  • ISBN-13: 9781138584044
Kitos knygos pagal šią temą:
Pastovi nuoroda: https://www.kriso.lt/db/9781138584044.html
Raktažodžiai:
Kinematics and Dynamics of Mechanical Systems: Implementation in MATLAB® and SimMechanics®, Second Edition combines the fundamentals of mechanism kinematics, synthesis, statics and dynamics with real-world applications, and offers step-by-step instruction on the kinematic, static, and dynamic analyses and synthesis of equation systems. Written for students with no working knowledge of MATLAB and SimMechanics, the text provides understanding of static and dynamic mechanism analysis, and moves beyond conventional kinematic conceptsfactoring in adaptive programming, 2D and 3D visualization, and simulation, and equips readers with the ability to analyze and design mechanical systems. This latest edition presents all of the breadth and depth as the past edition, but with updated theoretical content and much improved integration of MATLAB and SimMechanics in the text examples.

Features:











Fully integrates MATLAB and SimMechanics with treatment of kinematics and machine dynamics





Revised to modify all 300 end-of-chapter problems, with new solutions available for instructors





Formulated static & dynamic load equations, and MATLAB files, to include gravitational acceleration





Adds coverage of gear tooth forces and torque equations for straight bevel gears





Links text examples directly with a library of MATLAB and SimMechanics files for all users
Preface xiii
Authors xvii
1 Introduction to Kinematics
1(12)
