An illustrated guide to preparing construction drawings. 11x8.5<">. No bibliography. Annotation copyright Book News, Inc. Portland, Or.
From information on standard utility graphics through specifics on schedules and sequencing, this book covers every aspect of the working drawings and schedules that comprise a standard set of construction documents:
Site Plans
Floor Plans
Roof Plans
Reflected Ceiling Plans
Exterior Elevations
Building Sections
Wall Sections
Vertical Transportation Systems
Enlarged Plans and Interior Elements
Schedules Details
Step-by-step graphics illustrate the precise sequencing of each drawing, presenting a system that can be used, with some modification, on virtually any type or size of commercial building.
An invaluable teaching tool and reference.
