Meta-Smith Charts and Their Applications [Minkštas viršelis]

  • Formatas: Paperback / softback, 122 pages, aukštis x plotis: 235x187 mm
  • Serija: Synthesis Lectures on Antennas
  • Išleidimo metai: 30-Oct-2010
  • Leidėjas: Morgan & Claypool Publishers
  • ISBN-10: 1608455807
  • ISBN-13: 9781608455805
Kitos knygos pagal šią temą:
Meta-Smith Charts and Their ApplicationsDidesnis paveikslėlis
  • Formatas: Paperback / softback, 122 pages, aukštis x plotis: 235x187 mm
  • Serija: Synthesis Lectures on Antennas
  • Išleidimo metai: 30-Oct-2010
  • Leidėjas: Morgan & Claypool Publishers
  • ISBN-10: 1608455807
  • ISBN-13: 9781608455805
Kitos knygos pagal šią temą:
Pastovi nuoroda: https://www.kriso.lt/db/9781608455805.html
This book presents the developments and potential applications of Meta-Smith charts, which can be applied to practical and useful transmission line problems (e.g., metamaterial transmission lines and nonreciprocal transmission lines). These problems are beyond the capability of the standard Smith chart to be applied effectively. As any RF engineer is aware, a key property of the Smith chart is the insight it provides, even in very complex design processes. Like the Smith chart, Meta-Smith charts provide a useful way of visualizing transmission line phenomena. They provide useful physical insight, and they can also assist in solving related problems effectively. This book can be used as a companion guide in studying Microwave Engineering for senior undergraduate students as well as for graduate students. It is also recommended for researchers in the RF community, especially those working with periodic transmission line structures and metamaterial transmission lines. Problems are also provided at the end of each chapter for readers to gain a better understanding of material presented in this book.
Foreword I xiii
Foreword II xv
Preface xvii
List of Abbreviations
xxi
Acknowledgments xxiii
1 Essential Transmission Line Theory
1(16)
1.1 Introduction
1(1)
1.2 Transmission Line Equations
2(3)
1.3 Terminated Uniform Transmission Lines
5(3)
1.3.1 Terminated Lossy Uniform Transmission Lines
6(2)
1.3.2 Terminated Lossless Uniform Transmission Lines
8(1)
1.4 Terminated Nonuniform Transmission Lines
8(5)
1.4.1 Terminated Exponentially Tapered Lossless Nonuniform Transmission Lines
9(4)
1.5 Conclusions
13(1)
Bibliography
13(1)
1.6 Problems
14(3)
2 Theory of Conjugately Characteristic-Impedance Transmission Lines (CCITLs)
17(14)
2.1 Introduction
17(1)
2.2 Nonreciprocal Lossless Uniform Transmission Lines
18(1)
2.3 Reciprocal Lossless Uniform Transmission Lines
19(1)
2.4 Exponentially Tapered Lossless Nonuniform Transmission Lines
20(1)
2.5 Finite Reciprocal Lossless Periodic Transmission Line Structures
21(5)
2.6 Conclusions
26(3)
Bibliography
28(1)
2.7 Problems
29(2)
3 Theory of Bi-Characteristic-Impedance Transmission Lines (BCITLs)
31(10)
3.1 Introduction
31(1)
3.2 Nonreciprocal Lossy Uniform Transmission Lines
32(1)
3.3 Finite Reciprocal Lossy Periodic Transmission Line Structures
33(4)
3.4 Conclusions
37(2)
Bibliography
37(2)
3.5 Problems
39(2)
4 Meta-Smith Charts for CCITLs and BCITLs
41(26)
4.1 Introduction
41(1)
4.2 The Meta-Smith Chart for CCITLS with Nonnegative Characteristic Resistances
42(6)
4.2.1 The Z Meta-Smith Chart for CCITLs with NNCRs
42(2)
4.2.2 The Y Meta-Smith Chart for CCITLs with NNCRs
44(1)
4.2.3 Numerical Results
44(4)
4.3 The Meta-Smith Chart for CCITLS with Negative Characteristic Resistances
48(5)
4.3.1 The Z and Y Meta-Smith Charts for CCITLs with NCRs
49(1)
4.3.2 Numerical Results
49(4)
4.4 The Meta-Smith Chart for BCITLS
53(6)
4.4.1 The Z Meta-Smith Chart for BCITLs
54(2)
4.4.2 The Y Meta-Smith Chart for BCITLs
56(1)
4.4.3 Numerical Results
56(3)
4.5 Conclusions
59(4)
Bibliography
60(3)
4.6 Problems
63(4)
5 Applications of Meta-Smith Charts
67(16)
5.1 Introduction
67(1)
5.2 Nonreciprocal Stub Tuners
67(6)
5.2.1 Nonreciprocal Single-Stub Series Tuners
68(2)
5.2.2 Nonreciprocal Double-Stub Shunt Tuners
70(3)
5.3 Terminated Exponentially Tapered Lossless Nonuniform Transmission Lines
73(2)
5.3.1 Procedures of Using the Meta-Smith Chart
73(1)
5.3.2 Numerical Example
74(1)
5.4 Terminated Finite Reciprocal Lossless Periodic Transmission Line Structures with Nonnegative Characteristic Resistances
75(2)
5.5 CCITLS with Negative Characteristic Resistances
77(1)
5.6 Reciprocal Lossy BCITLS
78(1)
5.7 Conclusions
79(3)
Bibliography
80(2)
5.8 Problems
82(1)
A The Transmission (ABCD) Matrix
83(2)
Bibliography
84(1)
B The Required Condition for Nonreciprocal CCITLs
85(2)
Bibliography
85(2)
C Derivation of Z+0 = (Z-0) for CCITLs
87(2)
D Derivation of the Magnitude of the Voltage Reflection Coefficient at the Load for Terminated CCITLs
89(2)
E Power Consideration for Terminated Finite Reciprocal Lossless Periodic Transmission Line Structures
91(2)
Bibliography
92(1)
Author's Biography 93(2)
Index 95
