Method of Moments in Electromagnetics 2nd New edition [Kietas viršelis]

4.50/5 (3 ratings by Goodreads)
(Tripoint Industries Inc., Harvest, Alabama, USA)
  • Formatas: Hardback, 450 pages, aukštis x plotis: 234x156 mm, weight: 782 g, Meetings: ICASSP Meeting, May.in Florence , SIAM July, Chicago , Joint Math January, San Antonio; 10 Tables, black and white; 192 Illustrations, black and white
  • Išleidimo metai: 08-Jul-2014
  • Leidėjas: Apple Academic Press Inc.
  • ISBN-10: 148223579X
  • ISBN-13: 9781482235791
Kitos knygos pagal šią temą:
Method of Moments in Electromagnetics 2nd New editionDidesnis paveikslėlis
  • Formatas: Hardback, 450 pages, aukštis x plotis: 234x156 mm, weight: 782 g, Meetings: ICASSP Meeting, May.in Florence , SIAM July, Chicago , Joint Math January, San Antonio; 10 Tables, black and white; 192 Illustrations, black and white
  • Išleidimo metai: 08-Jul-2014
  • Leidėjas: Apple Academic Press Inc.
  • ISBN-10: 148223579X
  • ISBN-13: 9781482235791
Kitos knygos pagal šią temą:
Pastovi nuoroda: https://www.kriso.lt/db/9781482235791.html
Raktažodžiai:
"This book discusses the use of integral equations in electromagnetics, covering theory only when necessary to explain how to apply it to solve practical problems. To introduce the method of moments, coupled surface integral equations are derived and solved in several domains of pragmatic concern: two-dimensional problems, thin wires, bodies of revolution, and generalized three-dimensional problems. Focusing on real-world implementation, the Second Edition includes a treatment of electromagnetic scattering from objects that may be either conducting or comprise a composite conducting/dielectric (material) geometry. "--

The graduate textbook introduces the Method of Moments in the context of electrostatic field problems, derives coupled surface integral equations of radiation and scattering, and applies the Moment Method to thin wires, bodies of revolution, electromagnetic interference, electronics packaging, antenna impedance, radar cross section prediction, and the calculation of near fields. The second edition breaks the material on the solution of matrix equations into its own chapter, and adds material on dielectric objects. Annotation ©2014 Ringgold, Inc., Portland, OR (protoview.com)

Now Covers Dielectric Materials in Practical Electromagnetic Devices

The Method of Moments in Electromagnetics, Second Edition explains the solution of electromagnetic integral equations via the method of moments (MOM). While the first edition exclusively focused on integral equations for conducting problems, this edition extends the integral equation framework to treat objects having conducting as well as dielectric parts.

New to the Second Edition

  • Expanded treatment of coupled surface integral equations for conducting and composite conducting/dielectric objects, including objects having multiple dielectric regions with interfaces and junctions
  • Updated topics to reflect current technology
  • More material on the calculation of near fields
  • Reformatted equations and improved figures

Providing a bridge between theory and software implementation, the book incorporates sufficient background material and offers nuts-and-bolts implementation details. It first derives a generalized set of surface integral equations that can be used to treat problems with conducting and dielectric regions. Subsequent chapters solve these integral equations for progressively more difficult problems involving thin wires, bodies of revolution, and two- and three-dimensional bodies. After reading this book, students and researchers will be well equipped to understand more advanced MOM topics.
