Theories, Methods and Numerical Technology of Sheet Metal Cold and Hot Forming: Analysis, Simulation and Engineering Applications 2013 ed. [Kietas viršelis]

, , ,
  • Formatas: Hardback, 210 pages, aukštis x plotis: 235x155 mm, weight: 506 g, XIV, 210 p. With online files/update., 1 Hardback
  • Serija: Springer Series in Advanced Manufacturing
  • Išleidimo metai: 21-Jul-2012
  • Leidėjas: Springer London Ltd
  • ISBN-10: 1447140982
  • ISBN-13: 9781447140986
Kitos knygos pagal šią temą:
Theories, Methods and Numerical Technology of Sheet Metal Cold and Hot Forming: Analysis, Simulation and Engineering Applications 2013 ed.Didesnis paveikslėlis
  • Formatas: Hardback, 210 pages, aukštis x plotis: 235x155 mm, weight: 506 g, XIV, 210 p. With online files/update., 1 Hardback
  • Serija: Springer Series in Advanced Manufacturing
  • Išleidimo metai: 21-Jul-2012
  • Leidėjas: Springer London Ltd
  • ISBN-10: 1447140982
  • ISBN-13: 9781447140986
Kitos knygos pagal šią temą:
Pastovi nuoroda: https://www.kriso.lt/db/9781447140986.html
Raktažodžiai:
Over the last 15 years, the application of innovative steel concepts in the automotive industry has increased steadily. Numerical simulation technology of hot forming of high-strength steel allows engineers to modify the formability of hot forming steel metals and to optimize die design schemes. Theories, Methods and Numerical Technology of Sheet Metal Cold and Hot Forming focuses on hot and cold forming theories, numerical methods, relative simulation and experiment techniques for high-strength steel forming and die design in the automobile industry.Theories, Methods and Numerical Technology of Sheet Metal Cold and Hot Forming introduces the general theories of cold forming, then expands upon advanced hot forming theories and simulation methods, including:the forming process,constitutive equations,hot boundary constraint treatment, andhot forming equipment and experiments.Various calculation methods of cold and hot forming, based on the authors’ experience in commercial CAE software for sheet metal forming, are provided, as well as a discussion of key issues, such as hot formability with quenching process, die design and cooling channel design in die, and formability experiments.Theories, Methods and Numerical Technology of Sheet Metal Cold and Hot Forming will enable readers to develop an advanced knowledge of hot forming, as well as to apply hot forming theories, calculation methods and key techniques to direct their die design. It is therefore a useful reference for students and researchers, as well as automotive engineers.

This book introduces general principles of cold forming, then expands upon advanced hot forming theories and simulation methods, including the forming process, constitutive equations, hot boundary constraint treatment and hot forming equipment and experiments.
1 The Introduction of Sheet Metal Forming Technology
1(14)
1.1 The Development of Stamping Technology
1(3)
1.2 The Current Status of Stamping Technology
4(4)
1.2.1 The Application of Tailor Welded Blanks
4(1)
1.2.2 The Application of High Strength Sheet Steel
5(1)
1.2.3 Internal High Pressure Forming
5(1)
1.2.4 Finite Element Analysis of Formability and Forming Technology
6(1)
1.2.5 Manufacturing of Stamping Mold
7(1)
1.2.6 Stamping Equipments
8(1)
1.3 The Introduction of Hot Stamping Technology
8(7)
1.3.1 The Research Status of Hot Forming Material
9(1)
1.3.2 The Research Status of Hot Forming Technology
10(2)
1.3.3 The Analysis of the Vitality of Hot Forming Technology
12(1)
References
12(3)
2 The Basics and Equipments of Sheet Metal Forming
15(20)
2.1 Fundamentals of Cold Stamping
16(2)
2.1.1 The Process of Cold Stamping
16(1)
2.1.2 The Dies of Cold Stamping
16(2)
2.1.3 The Production Process of Stampings
18(1)
2.2 Materials for Cold Stamping and Its Formability
18(7)
2.2.1 Requirements on Materials for Cold Stamping
18(2)
2.2.2 The Formability of Materials
20(5)
2.3 Cold Stamping Equipments
25(2)
2.4 Brief Introduction of Key Equipments and Production Lines in Hot Forming
27(8)
2.4.1 Continuous Ring Heating Furnace
27(2)
2.4.2 High-Temperature Resistant Robot Arm and Automatic Transfer Device for Loading and Unloading
29(1)
2.4.3 Key Technologies for Design and Manufacture of Hot Forming Dies
30(1)
2.4.4 High Speed Hydraulic Press for Hot Forming
31(2)
2.4.5 Subsequent Shot Blasting, Trimming and Punching Equipment
33(1)
References
34(1)
3 Hot Forming Process
35(12)
3.1 Direct Hot Forming Process
35(4)
3.2 Indirect Hot Forming Process
39(3)
3.3 The Key Parameters and Optimal Control in Hot Forming process
42(5)
3.3.1 The Heating Temperature, Holding Time and Optimization Control
43(1)
3.3.2 Transfer Time of High Temperature Sheet
44(1)
3.3.3 Hot Forming Rate, Cooling Rate in Die and the Control of Them
44(1)
References
44(3)
4 The Basic Mechanical Properties and Experimental Verification for Hot Forming Steel
47(22)
4.1 The Plasticity and Deformation Resistance of Metal Induced by Thermal Deformation and Their Influencing Factors
47(1)
4.2 The Concepts of Plastic Deformation, Plasticity and Deformation Resistance
47(1)
4.3 Factors Influencing Plasticity and Deformation Resistance of Hot Forming Steel
48(6)
4.3.1 Chemical Composition
48(1)
4.3.2 Metallic Structure
49(1)
4.3.3 Deformation Temperature and Work Hardening
50(1)
4.3.4 Deformation Rate
51(2)
4.3.5 Cooling Rate
53(1)
4.3.6 Deformation Degree
53(1)
4.3.7 Size Factor
54(1)
4.4 Typical Type of High Strength Steel and Its Basic Mechanics Experiment in Hot Forming Process
54(11)
4.4.1 Typical Types of High-Strength Steel
54(3)
4.4.2 Basic Mechanical Properties of High Strength Steel at Room Temperature
57(1)
4.4.3 Uniaxial Tensile Experiment of High Strength Steel Under Elevated Temperature
57(4)
4.4.4 Effects of Directional Anisotropy on Formability
61(4)
4.5 Constitutive Laws of High Strength Steel
65(4)
References
66(3)
5 The Basic Theory and Constitutive Equation of High-Strength Steel for Hot Forming
69(16)
5.1 Multi-Field Coupled Relationship Among Heat, Stress, and Phase Transformation
69(9)
5.1.1 Theoretical Analysis
69(1)
5.1.2 The Determination of the Parameters
70(4)
5.1.3 The Analysis and Discussion on the Experiment Results
74(2)
5.1.4 Thermal-Mechanical Transformation Coupled Constitutive Model
76(2)
5.2 Hot Forming Stress and Strain Analysis
78(3)
5.2.1 Mixed Law
78(1)
5.2.2 Strain Analysis
79(1)
5.2.3 Stress Analysis
80(1)
5.3 Constitutive Model of Hot Forming
81(4)
5.3.1 Hot Forming Constitutive Relation of Total Strain Theory
81(1)
5.3.2 Hot Forming Constitutive Relation of Incremental Theory
82(1)
References
82(3)
6 Microscopic Constitutive Models of Single Crystal and Polycrystal
85(28)
6.1 Crystallography and Crystal Structure
85(9)
6.1.1 Lattice Geometry
85(2)
6.1.2 Crystal Direction Indice and Crystal Plane Indice
87(3)
6.1.3 Crystal Structure of Simple Metals
90(2)
6.1.4 Lattice Defects
92(2)
6.2 Plastic Deformation of Single Crystal
94(13)
6.2.1 Slip of Single Crystal
94(2)
6.2.2 Kinematics of Single Crystal's Finite Deformation
96(3)
6.2.3 Elastic-Plastic Constitutive Equations for Single Crystals
99(1)
6.2.4 A Thermo-Elasto-Viscoplastic Model for Single Crystal
100(7)
6.3 Polycrystal Plasticity Theory
107(6)
6.3.1 Taylor-Bishop-Hill Analysis
108(1)
6.3.2 Eshelby Inclusion Model
109(1)
6.3.3 Self-Consistent Scheme
109(2)
References
111(2)
7 Hot Forming Simulation Algorithms of High-Strength Steels
113(40)
7.1 Basic Descriptions of the Hot Forming Simulation
113(3)
7.2 Several Key Points in Numerical Simulation of Hot Forming
116(5)
7.2.1 Key Technology of Multi-Field Coupled
116(1)
7.2.2 Problems of High Temperature Contact Friction
117(1)
7.2.3 The Technology of Simulation of Temperature Field
118(1)
7.2.4 The Basic Formula of Heat Transfer in Hot Forming Process
119(2)
7.3 The Model Building and Simulation of Temperature Field in Hot Forming
121(9)
7.3.1 Theoretical Model of the Latent Heat
121(2)
7.3.2 The Basic Equation of Temperature Shell Elements
123(2)
7.3.3 Weak Form of Equivalent Integral for Weighted Residual Method for Shell Transient Temperature Field Problem
125(2)
7.3.4 Finite Element Formulation of Shell Temperature Element
127(2)
7.3.5 Discreteness of Space Domain and Time Domain in Shell Transient Temperature Field
129(1)
7.4 Static Explicit Algorithm for Hot Forming Multi-Field Coupled Numerical Simulation
130(7)
7.4.1 Hot Forming Multi-Field Coupled Constitutive Equation Based on Sustained Equilibrium Equations
130(3)
7.4.2 Finite Element Formula of Large Deformation
133(4)
7.5 Dynamic Explicit Finite Element Formulation of Multi-Filed Coupled Hot Forming Simulation
137(16)
7.5.1 Dynamic Equation of Single Degree of Freedom Damped System
137(2)
7.5.2 Central Difference Solving Format of Discrete Dynamic Equilibrium Equation
139(3)
7.5.3 Explicit Finite Element Algorithm of Large Deformation Dynamic in Continuum
142(4)
7.5.4 Internal Stress Calculation of Hot Forming
146(1)
7.5.5 Contact and Friction Models
147(2)
References
149(4)
8 Numerical Simulation of High Strength Steel Plate's Hot Forming
153(20)
8.1 The Static Explicit Simulation of Temperature Field and Martensite Transformation for Hot Forming for U-Shaped Steel
153(7)
8.2 Dynamic Explicit Simulation of Hot Forming for Door Reinforced Beam
160(7)
8.3 Numerical Simulation Result and Experimental Comparison of Hot Forming by Static Explicit Algorithm
167(2)
8.4 Summary
169(4)
References
171(2)
9 Features of Hot Forming Graded Composite Material and Its Experiment and Simulation
173(16)
9.1 Layered Hot Forming Composite Material and Parts
174(5)
9.1.1 Experimental and Microscopic Organizational Analysis of Layered Hot Forming Composite Material and parts
174(1)
9.1.2 Three-Point Bending Test and Finite Element Analysis of Metal Composite Material
175(3)
9.1.3 An Analysis of Crash Impact and Energy Absorption of Thickness Direction Gradient Composite
178(1)
9.2 Continuous Gradient Hot Forming Composite Part
179(10)
9.2.1 The Manufacturing Process of Continuous Gradient Hot Forming Composite Part
179(1)
9.2.2 Investigation of Microstructure and Mechanical Properties of Continuous Gradient Hot Forming Composite Parts
180(1)
9.2.3 Investigation of Impact Energy Absorption Performance of Continuous Gradient Hot Forming Composite Parts
181(7)
References
188(1)
10 Simulation and Optimization on Service Performance of Hot Forming Parts
189(18)
10.1 The Application Analysis of Hot Forming Parts in Body Lightweighting
189(4)
10.2 The Engineering Application of Hot Forming Gradient Composite Parts
193(8)
10.2.1 Optimization of Hot Forming Gradient Composite Case 1: B Pillar
193(5)
10.2.2 The Design of Hot Forming Gradient Composite Case 2-S beam
198(3)
10.3 The Case of Hot Forming Parts Applied in the Automotive Body Design
201(6)
10.3.1 The Design of Hot Forming Parts in the Vehicle Body Design
201(1)
10.3.2 The Functional Design of Hot Forming Parts in the Body Design
202(4)
References
206(1)
Index 207
Ping Hu is the dean of the School of Automotive Engineering in Dalian University of Technology (DUT), China, and a professor in the State Key Lab of Structural Analysis of Industrial Equipment in Dalian, China. Ping Hu is also the founder and CEO of KingMesh Company Ltd. He earned his BS, MS and PhD degrees in mathematical mechanics and computing mechanics at JiLin University of Technology (JUT), and completed his postdoctoral research in Kobe University, Japan. In the past, Ping Hu has been the deputy dean of the Graduate School at Jilin University (JLU), professor in the State Key Lab of Automobile Dynamic Simulation located at JLU, director of the Institute of Automobile Body and Die Engineering, and the CEO of Changchun KingMesh Auto Eng. Ltd.



Ning Ma is a technical expert in Zhejiang Geely Automobile Research Institute CO. LTD, and a researcher in the School of Automotive Engineering at Dalian University of Technology. He earned his PhD degrees in mechanical engineering at DUT and completed visiting doctoral research  in the Department of Mechanical Engineering, Northwestern University (NU), USA. In the past, Ning Ma worked as a senior project assistant in Advanced Materials Processing Laboratory, NU, USA, project manager, manufacturing and design engineer in Guangzhou Automobile Group Co., Ltd. And SAIC Motor Corporation Limited, China.



Li-zhong Liu and Yi-guo Zhu also work in the School of Automotive Engineering at Dalian University of Technology.
