There are two typical transient EM NDT methods, pulsed eddy current (PEC) and transient eddy current thermography (TECT) which are introduced and researched in this book. This book covers the three key areas of theories, methods, and applications: Theory: 1) Multi-physics field including eddy current, heat conduction, and Infrared radiation are studied for defect evaluation; 2) Lateral heat conduction is analysed to detect parallel cracks; 3) Longitudinal heat conduction is analysed to detect depth defect, which is beyond skin depth; Methods: 1) Time domain, frequency domain, and logarithm domain are analysed; 2) A-scan , B-scan, and C-scan are introduced and compared; 3) Defect identification, classification, quantification are analysed; 4) Advanced algorithm, principal components analysis (PCA), independent components analysis (ICA) and support vector machine (SVM) are used; 5) Image reconstruction is proposed to improve the detectability. Applications: 1) A lot of experimental studies on multi-layer aluminium structures, honeycomb structure, CFRP in aerospace field, steel and coating in marine field, rail in transportation field are provided; 2) A variety of real damages are evaluated, such as corrosion and blister in steel, stress in aluminium, impact and delamination in CFRP laminates, RCF cracks in rail.

  • Different from steady NDT testing, transient EM NDT testing is special. Two kinds of transient NDT testing are introduced from theory, methodology to applications.
  • Theoretically, multi-physics field including eddy current, heat conduction, Infrared radiation are studied for defect evaluation; lateral heat conduction is used to detect parallel cracks; longitudinal heat conduction is used to detect depth defect, which is beyond skin depth;
  • Methodologically, a lot of methods are analysed. Time domain frequency domain, and logarithm domain are analysed; A-scan , B-scan, and C-scan are introduced and compared; advanced algorithm principal components analysis (PCA), independent components analysis (ICA) and support vector machine (SVM) are used; Image reconstruction is used to improve the detectability;
  • In view of application, macro damage and micro properties variations including conductivity, permeability, and lift-off are evaluated; Experimental studies for real damages including corrosion and blister in steel, stress in aluminium, impact and delamination in CFRP laminates, RCF cracks are abundant.

Daugiau informacijos

The only English language book providing a comprehensive coverage of PEC and TECT
